EMCO EMCOTURN 332 MC PLUS CNC Lathe

Sorry, this machine has already been sold

Discover similar available machines

Machine details

Name   EMCO EMCOTURN 332 MC PLUS CNC Lathe
Item No.   450419
Manufacturer   EMCO
Model / Type   EMCOTURN 332 MC PLUS
Year of manufacture   2001
Machine available from   immediately
Machine condition   uncheckedSome of our machines cannot be tested by our project managers since they are not in a position to power the device. In cases such as these, we will be unable to guarantee the functionality of the item.
Machine location   82140 Olching, Germany

Description

Control System Siemens 840 D Turning diamater [mm] 140 Turning
length [mm] 480 Spindle bores [mm] 45 Main spindle: Speed: 6.300
rpm Power: 13 kW Torque: 53 Nm Bar capacity: 45 mm C-Axis: 0,001°, Sub spindle: Speed: 7.000 rpm,
Power: 10 kW Torque: 45 Nm Bar capacity: 32 mm C-Axis: 0,001, Tool carrier I: Turret: 12 stations Taper: VDI 25 Tool
drive: 6.000 rpm,5 kW, 12 Nm Travel X-Axis: 160 mm Travel Z-Axis:
510 mm Rapid traverse in X/Z: 20/24 m/min

ATTENTION: Loud humming noise at the counter spindle while starting the control system and heavily fluctuating power consumption.

Tool carrier II: Turret: 12 stations Taper: VDI 25 Tool drive: 6.000 rpm, 5 kW, 12 Nm TravelX-Axis: 140 mm

Equipment / Add-ons: Chip managment: Chip conveyor
Coolant mangament: Coolant pump Raw material feed: Gripper with
conveyor belt Finsihed part removal: Gripper with conveyor belt
Working area suction: Mechanical flter

By appointment you can inspectthe machine under power.

Technical details

Weight approx.   5,000 kg
Dimensions (l x w x h) approx.   4,300 x 3,420 x 2,550 mm

Costs and benefits

auction fee   15%
VAT   *plus VAT
Delivery terms   FCA Olching, loaded on truck
Cost Dismantling & Loading   950.00 € (binding)
Shipping costs   not included
Payment terms   100% payment prior to collection

Inspection

Location   No fixed date. The items are in different locations (see item
description). Viewing by appointment only!

Pick up

Date   The exact collection date is available on request.
