Auction 'Premium Dealer Machines for Metal Processing': lot no. 1

GILDEMEISTER TWIN 500 Linear CNC Lathe

GILDEMEISTER TWIN 500 Linear CNC Lathe

GILDEMEISTER TWIN 500 Linear CNC Lathe

Contact
Print
Watch
Please log in to accept the
terms and conditions .
Please log in
Please log in
Current highest bid:
0
0 Bids
Starting bid:
42,000 €
Bid now
Refresh
Closing time
04/09/2018 10:00 CET
(18 day(s) 16 hrs)
Bidding agent
plus auction fee and VAT
The additional cost is the sales commission, which is covered by the buyer. The surcharge will represent 15% of the final price plus VAT. The final price includes both the highest bid and commission costs.
Watch
Total Price Calculator

Machine details

Name   GILDEMEISTER TWIN 500 Linear CNC Lathe
Item No.   466515
Manufacturer   GILDEMEISTER
Model / Type   TWIN 500 Linear
Year of manufacture   2001
Machine available from   immediately
Machine location   Germany, 73529 Schwäbisch Gmünd
Machine condition   uncheckedSome of our machines cannot be tested by our project managers since they are not in a position to power the device. In cases such as these, we will be unable to guarantee the functionality of the item.

Description

CNC machining and milling center
GILDEMEISTER GMX 500 Linear
Year of construction 2001
CNC control SIEMENS 840 D

Technical Data
max. turning diameter 610 mm
max. turning length 1.850 mm
travel Y-axis (slide 1) 210 mm
travel B axis (slide 1) 240
face travel (slide 1/slide 2) 605/267 mm
longitudinal travel (slide 1/slide 2) 1,470/1,440 mm
longitudinal travel (slide 3) 1,490 mm
spindle bore 118 mm
tool spindle speed 4000 1/min
speed range stepless 20- 3,200 rpm.
torque at the spindle 650/1,080 Nm
speed range C-axis 3,200 rpm
rapid traverse (slide 1) 46/24 n/min
rapid traverse (slide 2) 24/60 m/min
total power requirement 130/180 KW
weight approx. 18,5 to.
space requirement as per AWF card (Lx Wx H) 8,000 x 4,000 x 3,200 mm

Equipment
main and counter spindle as integrated spindle motor
differential pressure clamping for main and counter spindle
drive power 69 KW (56 - 40% ED) each
separate speed limitation device for power chucks
tool magazine 40-fold (additional extension of the tool magazine by a 2nd chain with further 40 positions)
three-jaw power chuck with bore and quick-change jaw system FNC 250-72, Forkardt, incl. attachments for main spindle
support for counter-spindle
spindle flange with MKS holders and rotating tailstock center
In-process sensor Marposs
blowing air as an alternative to coolant
double clamping cylinder
adjustable setting force of the counter-spindle for tailstock operation via programming function 11
moving to fixed stop
measuring cycles: possibility to measure with a sensor on the C axis
The 5-axis simultaneous movement programs the axes: x; y; z; C and B.
4-track bed - roller guides
coolant spray gun
compact filter unit lnterlit
additional coolant pump, 80 bar, for upper tool carrier
chip conveyor
ethernet interface

Technical details

Weight approx.   22,000 kg
Dimensions (l x w x h) approx.   13,600 x 2,530 x 2,980 mm

Costs and benefits

auction fee   15%
VAT   *plus VAT
Delivery terms   FCA Schwäbisch Gmünd, free on truck
Shipping costs   not included
Payment terms   100% payment prior to collection

Total Price Calculator

Inspection

Location   73529 Schwäbisch Gmünd

Germany



- address on request -

Viewing by prior appointment only!
Date   Thursday, 30/08/2018, from 09:00 to 14:00

Pick up

Date   Monday, 10/09/2018 to Friday, 14/09/2018, from 08:00 to 17:00

Monday, 17/09/2018 to Friday, 21/09/2018, from 08:00 to 17:00
