KAMI DKM 500 S Center Lathe

Sorry, this machine has already been sold

Discover similar available machines

Machine details

Name   KAMI DKM 500 S Center Lathe
Item No.   469472
Manufacturer   KAMI
Model / Type   DKM 500 S
Machine available from   immediately
Machine location   Germany, 46342 Velen-Ramsdorf
Machine condition   uncheckedSome of our machines cannot be tested by our project managers since they are not in a position to power the device. In cases such as these, we will be unable to guarantee the functionality of the item.

Description

Center and turntable turning machine: - Large 103mm spindle bore - High cutting performance, optimum cutting results - Electromechanical spindle brake - Sophisticated gear design for transmitting the engine power in high Torques and strong cutting forces - Tuned, stiff construction for the absorption of large cutting forces - Tailstock construction with large radius for the machining of long waves - Feed operation via one-hand lever technology with rapid traverse function Delivery: 3-jaw chuck 315 mm, 4-jaw face chuck 400 mm, 1 piece running bezel, 1 piece standing bezel, 120-250 mm passage. Turning diameter over bed 500 mm Turning diameter over support 300 mm Turning length 2000 mm Turning diameter in the crank 710 mm Speed ​​36 - 1600 rpm Top height 250 mm Spindle bore 103 mm Tailstock sleeve mount MK 5 MK Tailstock stroke 150 mm Tailstock quill diameter 75 mm Total power requirement 7.5 kW Machine weight approx. 3.15 t Space required approx. 3.65 x 1.0 x 1.3 m

Technical details

Weight approx.   3,150 kg
Dimensions (l x w x h) approx.   3,650 x 1,000 x 1,300 mm

Costs and benefits

auction fee   15%
VAT   *plus VAT
Delivery terms   FCA Velen-Ramsdorf, loaded on truck
Cost Dismantling & Loading   220.00 € (binding)
Shipping costs   not included
Payment terms   100% payment prior to collection

Inspection

Location   Viewing by prior appointment only!



46342 Velen

Germany



Address on request only!
Date   Thursday, 17/01/2019, from 09:00 to 15:00

Pick up

Date   Wednesday, 23/01/2019 to Thursday, 24/01/2019, from 08:00 to 17:00

Friday, 01/02/2019 to Friday, 01/02/2019, from 08:00 to 13:30

Monday, 04/02/2019 to Thursday, 07/02/2019, from 08:00 to 17:00

Friday, 08/02/2019 to Friday, 08/02/2019, from 08:00 to 13:30

Friday, 25/01/2019 to Friday, 25/01/2019, from 08:00 to 13:30

Monday, 28/01/2019 to Thursday, 31/01/2019, from 08:00 to 17:00
