TRAUB TNX 65 CNC Turn-/Mill Centre

Sorry, this machine has already been sold

Discover similar available machines

Machine details

Name   TRAUB TNX 65 CNC Turn-/Mill Centre
Item No.   493356
Manufacturer   TRAUB
Model / Type   TNX 65
Year of manufacture   2006
Machine available from   immediately
Machine location   Germany, 82140 Olching
Machine condition   in working order

Description

TRAUB TNX 65 CNC Turn-/Mill Centre

Main spindle:
Technology: Hollow shaft motor
Speed: 5.000 rpm
Power: 22,6 kW
Torque: 180 Nm
Bar capacity: 65 mm
C-Axis: 500 rpm
3-jaw chuck: Röhm KFD-HS 170

Sub spindle:
Technology: Hollow shaft motor
Speed: 5.000 rpm
Power: 22,6 kW
Torque: 180 Nm
Bar capacity: 65 mm
C-Axis: 500 rpm
3-jaw chuck: Röhm KFD-HS 170

Tool carrier I (X/Y/Z/B):
Technology: Verticalturret, 8-fold
Milling operations: Tooldrive
B-Axis: 360°, 325 rpm, 75 Nm
Serration B-Axis: 2,5° divide
Movement X/Y/Z-Axis: 290/165/600 mm
Rapid traverse X/Y/Z-Axis: 18/18/30 m/min

Tool carrier II (X/Y/Z):
Technology: Turret, 10 stations
Taper: VDI 40
Tool drive: 6.000 rpm, 5,8 kW, 18,6 Nm
Movement X/Z-Axis: 170/600 mm
Movement Y-Axis: +/- 60 mm
Rapid traverse in X/Y/Z-Axis: 18/15/30 m/min

Equipment / Accessories:
Chipmanagement: Chip conveyor
Coolingmanagement: Internal cooling unit with paperbeltfilter
Fire-extinguishing system: Kraft+Bauer
Weight counterbalance: Hydraulic
Oil mist seperator: Preparation

transportation dimensions:
Machine: 4.500 x 2.550 x 2.550 mm, approx.. 14.000 kg
Chip conveyor: 5.500 x 1.000 x 1.700 mm, approx. 500 kg
Cooling unit: 1.600 x 1.400 x 1.600 mm, approx. 600 kg
Pallet with accessorie: 1.200 x 800 x 1.000 mm, approx. 100 kg

see also PDFs

Technical details

turning length   900 mm
control   MITSUBISHI TX-8i
toolchanger positions   10
number of places for driven tools   10
spindle bore   65 mm
tool taper   VDI 40
turning speed range   5,000 rpm
total power requirement   95 kW
Weight approx.   14,000 kg
Dimensions (l x w x h) approx.   6,000 x 3,000 x 2,500 mm

Costs and benefits

auction fee   15%
VAT   *plus VAT
Delivery terms   FCA Olching, loaded on truck
Cost Dismantling & Loading   950.00 € (binding)
Shipping costs   not included
Payment terms   100% payment prior to collection

Inspection

Location   No fixed date. The items are in different locations (see item
description). Viewing by appointment only!

Pick up

Date   The exact collection date is available on request.
