Auction 'Closure of a Toolmaker: low starting prices - no minimum prices': lot no. 43

WMW MIKROMAT 9 B Jig Boring Machine

DECKEL FP 3 Tool Milling Machine

DECKEL FP 3 Tool Milling Machine

WMW MIKROMAT 9 B Jig Boring Machine

WMW MIKROMAT 9 B Jig Boring Machine

Please log in to accept the
terms and conditions .
Please log in
Please log in
Current highest bid:
0
0 Bids
Starting bid:
2,150 €
Bid now
Refresh
Closing time
07/06/2018 9:17 CET
(13 day(s) 17 hrs)
Bidding agent
plus auction fee and VAT
The additional cost is the sales commission, which is covered by the buyer. The surcharge will represent 15% of the final price plus VAT. The final price includes both the highest bid and commission costs.
Watch
Total Price Calculator

Machine details

Name   WMW MIKROMAT 9 B Jig Boring Machine
Item No.   447812
Manufacturer   WMW
Model / Type   MIKROMAT 9 B
Year of manufacture   1989
Machine available from   immediately
Machine condition   uncheckedSome of our machines cannot be tested by our project managers since they are not in a position to power the device. In cases such as these, we will be unable to guarantee the functionality of the item.
Machine location   20-234 Lublin, Poland

Description

2-column-coordinate drilling machine, connected load max. 16 kVA, working range: longitudinal travel (X) 1120 mm, cross adjustment (Y) 710 mm, height adjustment (W) 630 mm, stroke of drilling spindle (Z) 315 mm, distance between table and spindle head 0 to 880 mm, passage between the columns 1080 mm, clamping table 900 x 1400 mm, clamping surface 1.26 m², table height over floor 865 mm, permitted table load 1000 kg, drilling spindle tool holder cone SK 45, speed range 36 to 2240 UpM, speed limit 180 rpm, torque step 1 (speed range 1) 36 to 180 rpm = 200 Nm, step 2 (speed range 2) 180 to 2240 rpm = 2000 Nm, feeds: Z-axis 0.025 to 2,24 mm/rotation, X- and Y-axis 22.4 to 710 mm/Min., rapid traverse Z-axis 2500 mm/Min., rapid traverse W-axis 1400 mm/min., reading accuracy X-axis 0.001 mm, Y-axis 0.001 mm, Z-axis 0,001 mm, W-axis 1 mm, positioning accuracy X-axis 0.003 mm, Y-axis 0.003 mm, including swivel and tilting table WMW 500 S, technical data turning diameter of the tabletop 500 mm, table rotation angle range 360 °, reading possibility at scale ring 1°, swivel angle range 90°, permitted workpiece weight max. 80 kg, see photos and PDF for details

Technical details

Weight approx.   10,000 kg
Dimensions (l x w x h) approx.   4,000 x 2,600 x 2,900 mm

Costs and benefits

auction fee   15%
VAT   *plus VAT
Delivery terms   FCA Lublin, loaded on truck
Cost Dismantling & Loading   2,500.00 € (binding)
Shipping costs   not included
Payment terms   100% payment prior to collection

Total Price Calculator

Inspection

Location   Viewing by prior appointment only!

- address on request -



20-234 Lublin • Poland

Pick up

Date   Monday, 18/06/2018 to Friday, 22/06/2018, from 08:00 to 16:00

Monday, 25/06/2018 to Tuesday, 26/06/2018, from 08:00 to 16:00
