Price On request

Costs and benefits

Delivery terms   FCA Appenweier, loaded on truck
Cost Dismantling & Loading   16,000.00 € (binding)
Shipping costs   not included
Payment terms   100% payment prior to collection

Machine details

Name   GILDEMEISTER GMC 70 F-ISM CNC-Multi-spindle turning center
Item No.   488894
Manufacturer   GILDEMEISTER
Model / Type   GMC 70 F-ISM
Year of manufacture   2004
Machine available from   immediately
Machine location   Germany, 77767 Appenweier
Machine condition   uncheckedSome of our machines cannot be tested by our project managers since they are not in a position to power the device. In cases such as these, we will be unable to guarantee the functionality of the item.

Technical details

turning diameter   215 mm
control   SIEMENS 840 D
toolchanger positions   3 x 12
number of controlled axles   16
spindle bore   70 mm
tool taper   VDI 30
turning speed range   3,000 rpm
rapid travel range   15/20 m/min
Weight approx.   20,000 kg
Dimensions (l x w x h) approx.   9,245 x 1,940 x 2,530 mm

Description

GILDEMEISTER GMC 70 F-ISM CNC-multi-spindle turning center


Spindle data

- Number of spindles: 4 (3 x main spindle 1 x counter spindle)
- Diameter of clamping chuck: 215 mm
- Max. speed main spindle & counter spindle: 3,000 rpm
- Travel counter spindle: 920 mm
- Rapid traverse counter spindle: 20 m/min
- Drive power spindle motors (40/ 100% duty cycle): 11.2/ 14.9 kW

Tools and tool turrets

- 3 tool turrets
- 3 x 12 tool places for driven tools
- Max. speed driven tools: 6000 rpm
- Power tool drive (40/ 100% duty cycle): 4/ 11.6 kW
- Tool holder: VDI 30
- Tool changing time (tool to tool): 0.6 s
- Rapid traverse X - axis: 15 m/min
- Rapid traverse Z - axis: 20 m/min
- Travels X1, X2: 155 mm
- Travel X3: 180 mm
- Travels Z1, Z2: 565 mm
- Travel Z3: 580 mm

Frontal slide

- 2 frontal slides each with 2 tool places
- Tool holder: VDI 30
- Tool chainging time: 0.3 s
- Rapid traverses W1, W2: 20 m/min
- Rapid traverses U1, U2: 15 m/min
- Travel W1, W2: 565 mm
- Travel U1, U2: 110 mm

General data

- Total switch-on time: 44080 h
- Spindle switch-on time: 25354 h
- 2 coolant pumps
- Coolant tank volume: 1200 l
- 400 V; 160 A; 100 kVA
- CE standards

Please look to the information in PDF format, a video is also available!
Machine can be inspected under power!
