Price On request

Costs and benefits

Delivery terms   FCA, loaded on truck
Cost Dismantling & Loading   32,000.00 € (binding)
Shipping costs   not included
Payment terms   100% payment prior to collection

Machine details

Name   HOMAG - HOLZMA - BARGSTEDT TFL 420 / HKL 380 / KFL 610 Flex Production Cell "Lot Size 1" with Laser
Item No.   474990
Manufacturer   HOMAG - HOLZMA - BARGSTEDT
Model / Type   TFL 420 / HKL 380 / KFL 610
Year of manufacture   2008
Machine available from   July 2019
Machine location   Germany
Machine condition   good

Technical details

Dimensions (l x w x h) approx.   1 x 1 x 1 mm
Weight approx.   1 kg

Description

Well-kept and professional Flex-Line BARGSTEDT TFL 420 - HOLZMA HKL 380 - HOMAG KFL 610 Flex Production Cell "Lot size 1" with Laser Edging, Power Controll PC22 control, flexible edge sequence control and equipping in the gap for significant increase of the production time! There are 2 HOMAG KFL 610 edge banding machines located opposite each other in the production cell. The plant has an original list price of approx. 3.3 million EUR and will be available in July 2019!

BARGSTEDT TFL 420/40/16 storage system
For continuous handling of plates.

Technical data:
- Workpiece lengths 2,000 - 4,300 mm
- Workpiece widths 800 - 2,200 mm
- Workpiece weight max. 250 kg
- Drive trolley v = approx. 8 - 90 m/min.
- Lift drive v = approx. 8 - 60 m/min.
- Drive bridge v = ca. 8 - 70 m/min.
- Rotary drive 90°

HOLZMA Profi HKL 380/38/22/L/X angular plate dividing saw with Speed Concept
+ Significantly higher speed and dynamic accelleration of the saw carriage
+ Enormous acceleration of the program fence
+ Liftable collets (crosscut saw)
+ Central angle pressure device
+ Electronic height control of the pressure beam
+ Power Control CADmatic 4

Technical data:
- Cutting length longitudinal saw 3,800 mm
- Cutting length crosscut saw 2,200 mm
- Saw blade projection 95 mm
- Main saw motor 2 pcs. each 18.0 kW
- Scoring saw motor 2 pcs. each 2.2 kW
- 1 pc. collet "Power-Concept" (3-finger) pos. 100 mm
- Saw carriage feed forward 1 - 150 m/min
- Saw carriage feed backward constant 150 m/min
- Program fence speed forward EU countries 25 m/min
- Program fence speed backward longitudinal saw 90 m/min
- Program fence speed backward crosscut saw 140 m/min
- Automatic pressure beam height control
- Automatic cutting height adjustment
- Adjustable pressure beam contact pressure
- Collet activation
- Collet longitudinal saw 4 pcs.
- Collet crosscut saw 7 pcs.
- Entirely jetted machine table (saw body)
- Automatic rotary unit for head cuts

BARGSTEDT TFR 560/G/28/41/12 roller conveyor
For straight conveying of workpieces.

BARGSTEDT multi-level storage with 25 individual levels
Each one workpiece can be stored intermediately per level.

Technical details:
- Workpiece length min. 250 mm
- Workpiece length max. 2,800 mm
- Working width max. 1,500 mm
- Conveying speed 10 - 50 m/min.

BARGSTEDT TFW 510/R/RR/25/12/Q angular transfer 90°

BARGSTEDT PROFI TDK 510/25/12 rotary station from longitudinal to cross

HOMAG Profi KFL 610/19/QA edge banding machine with laser
Unilateral HOMAG format processing and edge banding machine.
Fix fence side left and with flexible workpiece infeed system WZ 10.

Technical data:
- Feed steplessly adjustable 10 - 40 m/min.
- Workpiece thickness 8 - 40 mm
- Working width min. 85 mm
- Compact double hogger KD11 longitudinal/cross
(1 motor4.5 KW / 2 motors each 6.6 KW)
- Gluing unit A3 with 24-fold roller magazine
- Servo edging feed and edge hold-down clamp
- Laser unit for melting of the laser activation coating on edge material
- Pressure zone C with automatic adjustment
- Depth cutting saw on the opposite side
(scoring engine 2.2 KW / cutting engine 6.6 KW)
- End trimming unit HL84 (2 x 0.8 KW)
- Rough trimming unit top/bottom (2 x 0.55 KW)
- Profile trimming unit FK13 automatic 8-fold WW, servo driven
- Multi profile scraper MN21 automatic
- Flat scraper
- Buffer unit
- Standard milling unit 6.6 KW pneumatic control and stepless axis

HOMAG Profi TWL 41/25/L/Q angular transfer longitudinal and cross

HOMAG Profi KFL 610/19/QA edge banding machine with laser
Unilateral HOMAG format processing and edge banding machine.
Fix fence side left and with flexible workpiece infeed system WZ 10.

Technical data:
- Feed steplessly adjustable 10 - 40 m/min.
- Workpiece thickness 8 - 40 mm
- Working width min. 85 mm
- Compact double hogger KD11 longitudinal/cross
(1 engine 4.5 KW / 2 engines each 6.6 KW)
- Gluing unit A3 with 24-fold roller magazine
- Servo edging feed and edge hold-down clamp
- Laser unit for melting of laser activation coating on edge material
- Pressure zone C with automatic adjustment
- End trimming unit HL84 (2 x 0.8 KW)
- Rough trimming unit top/bottom ( 2 x 0.55 KW)
- Profile milling unit FK13 automatic 8-fold WW, servo driven
- Multi profile scraper MN21 automatic
- Flat scraper
- Buffer unit
- Standard milling unit 6.6 KW pneumatic control and stepless axis
