Price On request

Costs and benefits

Delivery terms   FCA, loaded on truck
Cost Dismantling & Loading   2,400.00 € (binding)
Shipping costs   not included
Payment terms   100% payment prior to collection

Machine details

Name   HOMAG Optimat BOF 311/30/PM/AP CNC Machining Center with FLEX5
Item No.   362443
Manufacturer   HOMAG
Model / Type   Optimat BOF 311/30/PM/AP
Year of manufacture   2008
Machine available from   at once
Machine location   Germany
Machine condition   good

Technical details

working length x-axis   3.050 mm
working width y-axis   1.700 mm
travelling way Z-axis   600 mm
path-feed rate max. X-axis   80 m/min
path-feed rate max. Y-axis   80 m/min
path-feed rate max. Z-axis   30 m/min
c-axis   ja / yes / FLEX5
tool changer   18-fach / 18-fold
main spindle   15 kW
vacuum pump   100 + 250 cbm/h
drilling head vertical x-axis   5 piece
drilling head vertical y-axis   4 piece
drilling head horizontal x-axis   2 piece
drilling head horizontal y-axis   2 piece
control   power control PC85
software   WoodWOP 5.0
Weight approx.   7,000 kg

Description

Technically very well kept and High-End equipped HOMAG Optimat BOF 311/30/PM/AP CNC Machining Center for the machining of wooden windows and entrance doors with FLEX5 unit, AP console table, matrix grid plate with BECKER vacuum pump, LAP ceiling laser, video camera, LEITZ window set IV 66/68 etc. The HOMAG CNC-machine has very little operating hours (MDE 1,765 h) and is located in a timber academy.

Technical data and equipment:
- Workpiece length for single placement (milling cutter Ø 25 mm) max. 3,225 mm
- Workpiece length for single placement (all units) max. 3,050 mm

- Workpiece width in front (milling cutter Ø 25 mm) max. 1,525 mm
- Workpiece width at the back (milling cutter Ø 25 mm) max. 1,850 mm
- Workpiece width in front (all units) max. 1,450 mm
- Workpiece width at the back (all units) max. 1,700 mm

- Automatic console positioning AP via toothed belts
- Matrix-adapter plate 1,550 x 1,550 mm (grid grooved plastic plate)
- Whithout Scantling clamp
- FLEX5 unit for the tool changer
- Saw unit High Performance for the tool changer
- Drill head 3+1 spindles horizontal for the tool changer
- Milling-sawing unit 2 spindles for the tool changer

(Further tools and units for the tool changer are not included within delivery. A transport rack from HOMAG is required for transportation of the dismantled machine. This results in costs of EUR 5,500,-- (plus tax). After the transport rack has been returned to SURPLEX, this amount minus a 10 % value deduction is refunded.)
