HOMAG PROFI KAR 330/9/A 20 Edgebander (100mm)

Edgebander Components

Edgebander Components

BIESSE ARTECH AKRON 650 Edgebander

BIESSE ARTECH AKRON 650 Edgebander

Price On request

Costs and benefits

Delivery terms   FCA Korschenbroich, loaded on truck
Cost Dismantling & Loading   2,000.00 € (binding)
Shipping costs   not included
Payment terms   100% payment prior to collection

Machine details

Name   HOMAG PROFI KAR 330/9/A 20 Edgebander (100mm)
Item No.   458819
Manufacturer   HOMAG
Model / Type   PROFI KAR 330/9/A 20
Year of manufacture   2012
Machine available from   immediately
Machine location   Germany, 41352 Korschenbroich
Machine condition   uncheckedSome of our machines cannot be tested by our project managers since they are not in a position to power the device. In cases such as these, we will be unable to guarantee the functionality of the item.

Technical details

serial number   0-200-35-0132
edge thickness   0,3 - 3 / 0,4 - 20 mm
workpiece thickness   8 - 100 mm
workpiece overhang   40 mm
workpiece width min.   60 mm
feed   18 - 25 m/min
joint trimming unit   WD 100 (2 x 4 kW)
gluing unit   2 Stück / 2 pieces QA 34 / A 20 / PU 34
edge magazine with   1 -fold roller
snipping unit   WK 14 (2 x 0,8 kW)
rough trimming unit   BF 20 (2 x 1,5 kW)
profile trimming unit   FK 21 (2 x 0,4 kW)
universal trimming unit   UF 11
profile scraping unit   MN 21
edge buffing unit   ja / yes
control   Power Control PC 22
Dimensions (l x w x h) approx.   13,000 x 2,200 x 2,000 mm
Weight approx.   8,000 kg

Description

Machine number 0-200-35-0132, installation surface approx. 11000 x 3000 mm, without cabinets in front of the machine which can be seen on the photos, 2 gluing units, including nitrogen container,

- Preparation for Lasertec
- Automatic adjustment pressure zone
- Coolant sprayer top / bottom
- Pneumatic adjustment sniping unit
- Pneumatic adjustment rough trimming unit BF 10 + 20
- Lubricant spray unit 4 nozzles
- Multi-scraper blade MN 21 max. 5 different profiles
