2 x INNSE BERARDI Atlas 3 RMI Portal Milling Machines with 5-fold pallet station

INNSE BERARDI Atlas 3 RMI Portal Milling Machine

INNSE BERARDI Atlas 3 RMI Portal Milling Machine

INNSE BERARDI Atlas 3 RMI Portal Milling Machine

INNSE BERARDI Atlas 3 RMI Portal Milling Machine

Contact
Print
Watch
Videos (1)
Request
Price On request

Costs and benefits

Delivery terms   EXW Schwerin, ex foundation, unpackaged
Cost Dismantling & Loading   If requested, we can also load your equipment onto the truck for a price of 250,000.00 EUR. Simply get in touch.
Shipping costs   not included
Payment terms   100% payment prior to collection

Machine details

Name   2 x INNSE BERARDI Atlas 3 RMI Portal Milling Machines with 5-fold pallet station
Item No.   422524
Manufacturer   INNSE BERARDI
Model / Type   Atlas 3 RMI
Year of manufacture   2009
Machine available from   immediately
Machine location   Germany, 19061 Schwerin
Machine condition   good

Technical details

x-travel   13,000 mm
y-travel   6,000 mm
z-travel   2000 + ( W 2500 ) mm
control   Siemens Sinumerik 840 D
table surface area l x w   3500 x 10000 mm
no. of milling heads horizontal   4 + ( 2 x Universal )
no. of milling heads vertical   6
distance between columns   5,200 mm
distance between spindle/table   4,700 mm
tool taper   ISO 60 / ISO 50 Tape Adapter
turning speed range   5-2500 rpm
feed range   6000 - 10000 mm/min
rapid traverse   6000 - 15000 m/min
Weight approx.   500,000 kg
Dimensions (l x w x h) approx.   30,000 x 50,000 x 12,000 mm

Description

INNSE BERARDI is belonging to the CAMOZZI Group Machine Type Atlas 3 RMI.
Here we offer 2 Portal Milling Machines with 5 axis portal with 5-fold FMS (Flexible Manufacturing System)
dimensions Table size 3.500 x 10.000 mm


Table dimensions 3.500 x 10.000 mm (5 x)
Table loading capacity 90.000 kg

Ram and spindle
Power 100 kW max. nominal torque 9000 Nm
Width of ram 550x550 mm (Z)
Width of cross-rail 1550 mm (Y)
C axis is build-in the ram rotating-around Z axis indexing 4 positions x 90° (0-360°)
8 milling heads per machine

Layout plan + further technical data available as PDF document.

The photos are out of current operation, the machine is offered without work pieces, clamping and fixing devices and without tools!

Goods covered by this document are potentially subject to the EG Dual Use Regulation Nr. 428/2009. Export license required for export out of EU.
