JUNKER Quickpoint 5000/40 CNC Cylindrical Grinder

JUNKER Quickpoint 5000/40 CNC Cylindrical Grinder

Price On request

Costs and benefits

Delivery terms   FCA Magdeburg, loaded on truck
Cost Dismantling & Loading   8,900.00 € (binding)
Shipping costs   not included
Payment terms   100% payment prior to collection

Machine details

Name   JUNKER Quickpoint 5000/40 Cylindrical Grinder
Item No.   411218
Manufacturer   JUNKER
Model / Type   Quickpoint 5000/40
Year of manufacture   2010
Machine available from   immediately
Machine location   Germany, 39126 Magdeburg
Machine condition   good

Technical details

grinding diameter   280 mm
grinding length   900 mm
table slide longitudinal travel max.   1,340 mm
control   FANUC 18 Ti
grinding wheel size   400 x (7 / 15 / 21) x 127 mm
grinding wheel turining speeds   6,000 Rpm
workpiece weight max.   130 kg
total power requirement   64 kVA kW
Weight approx.   19,000 kg
Dimensions (l x w x h) approx.   8,800 x 3,500 x 3,000 mm

Description

JUNKER Quickpoint 5000/40 CNC Cylindrical Grinding Machine

- machine no. 2641
- operating time (02.05.2018): 30485 h
- production time (02.05.2018): 19005 h
- The machine is designed for grinding outside diameters and the two face sides on wheels or for shaft grinding.
- workpiece clamping length max. 1000 mm
- workpiece spindle speed 8000 rpm
- grinding spindle speed 6000 rpm
- incl. oil coolant device
- suction system LTA
- combined CBN grinding disks for shoulder grinding, peel grinding, plunge grinding (free of twists)

- FANUC 18 Ti CNC control, JUNKER control panel and software JUWOP/R, JUWOP/R-DI, JUWOP/R-P and DPRO
- data backup by EJOP

integrated grinding disk balancing system with start sensor technology
consisting of:
-1 balancing head
-1 vibration sensor
-1 sender/receiver
-1 electronic control system
-1 documentation
- sharpening device

MOVOMATIC measuring device
This measuring device measures the workpiece in the grinding machine and passes the measured value on to the machine’s control device. Before starting the grinding process the workpiece is positioned lengthwise to a reference surface. Furthermore, it is possible to measure the length between the reference surface and a second surface which is to be machined. Additionally, the machined workpiece’s diameter is measured by a diameter measuring measurement head.
- static with automatic measurement correction
measuring head for measuring diameters:
- measuring range: 4 mm
measuring head for measuring lengths (per measuring head)
- measuring range ± 2 mm
- max. width for collar width measuring: 2-75 mm

For further details please see the attached technical data (PDF) and the machine video.
