NISSEI ASB MACHINE ASB 650 NH II Blow Moulding Machine

Price On request

Costs and benefits

Delivery terms   FCA Santa Comba - La Coruña, free on truck
Shipping costs   not included
Payment terms   100% payment prior to collection

Machine details

Name   NISSEI ASB MACHINE ASB 650 NH II Blow Moulding Machine
Item No.   353808
Manufacturer   NISSEI ASB MACHINE
Model / Type   ASB 650 NH II
Year of manufacture   2008
Machine available from   immediately
Machine condition   unchecked
Machine location   15840 Santa Comba - La Coruña, Spain

Technical details

Dimensions (l x w x h) approx.   7,230 x 2,400 x 2,850 mm
Weight approx.   21,000 kg

Description

NISSEI ASB MACHINE ASB 650 NH II
-One stage biaxial orientation
-Machine No. 309A50560
-Working hours 28510 12 injection cavity
-12 blow cavity
-driving power 90 kW Injection unit type IU-110
-hydraulic circuit pressure: 140 bar
-screw diameter 75 mm
-Injection capacity 1060 cm3/shot
-injection rate: 321 *1 cm3/shot (max)
-injection pressure 1310 bar
-screw stroke 240 mm
-screw rotation speed: 0-120 r/min
-Blowing pressure 245 N/cm2
-Injection mold clamp station: DL 510
-hydraulic circuit pressure: 140 bar
-Clamping force upper/lower: 949 kN / 508 kN
-Clamping stroke upper/lower: 400 mm / 300 mm Heating station
-heating core stroke: 350 mm
-heating core cylinder diameter: 80 mm
-heating pot stroke: 200 mm
-heating pot cylinder diameter: 80 mm
-Stretch blow mold clamp station stretch stroke: 200 mm
-Stretch cylinder diameter: 100 mm
-Stretch force 7,8 kN
-Blow core stroke: 300 mm
-blow core cylinder diameter: 125 mm
-blow core clamping force: 12,2 kN
-blow mold clamping force (AT 14,0 MPa): 494 kN
-blow mold clamping stroke: 490 mm
-blow mold plate size: 1040 x 370 mm
-Bottle eject station
-ejector stroke: 185 mm
-ejector cylinder diameter: 80 mm
-Further technical datas are attached as PDF
-Also some molds are included
