PIETRO CARNAGHI ATF 10 TM Vertical Turret Lathe

TOS SKIQ CNC Vertical Turret Lathe

TOS SKIQ CNC Vertical Turret Lathe

Price On request

Costs and benefits

Delivery terms   EXW Ruhstorf, ex foundation, unpackaged
Cost Dismantling & Loading   If requested, we can also load your equipment onto the truck for a price of 10,000.00 EUR. Simply get in touch.
Shipping costs   not included
Payment terms   100% payment prior to collection

Machine details

Name   PIETRO CARNAGHI ATF 10 TM Vertical Turret Lathe
Item No.   477695
Manufacturer   PIETRO CARNAGHI
Model / Type   ATF 10 TM
Year of manufacture   2000
Machine available from   Beginning 2019
Machine location   Germany, 94099 Ruhstorf
Machine condition   uncheckedSome of our machines cannot be tested by our project managers since they are not in a position to power the device. In cases such as these, we will be unable to guarantee the functionality of the item.

Technical details

swing diameter   1,200 mm
faceplate diameter   1,150 mm
turning height   750 mm
workpiece weight max.   2,000 kg
faceplate turning speed range   5,5-1000 rpm
cross rail adjustment   + 710 / -710 mm
feed range   0,1 - 3000 mm/min
rapid travel range   15 m/min
Weight approx.   25,000 kg
Dimensions (l x w x h) approx.   7,000 x 5,000 x 4,500 mm

Description

PIETRO CARNAGHI ATF 10 TM CNC Vertical Turret Lathe


CNC control by SIEMENS SINUMERIK 840 D
Crossbar support with chisel slide for turning, milling and drilling


Technical specifications

- Toolchanger for 80 tools
- Hydraulic clamping chuck

Faceplate

- Faceplate power: 60 kW
- Max. torque faceplate: 4179 Nm
- Stepless faceplate speeds in 2 gear stages: 5,5 - 1000 rpm

Milling

- Torque 4179 Nm
- Stepless C-axis speed: 0,01 - 7 rpm
- Angular position programmable from: 0,001°
- Clamping torque of the hydraulic clamping: 27000 N

Crossbar support with chisel slider for turning,
drilling and milling (hydrostatics in X and Z axis)

- Chisel slider : 250 x 250 mm
- Tool holder turning: CAPTO - C6
- Tool holder drilling und milling: HSK 100 A
- max. cutting force: 34.000 N
- Feed force X- and Z-axis: 30.000 N
- Stepless speed range in 2 steps: 10 – 3.000 rpm.
- Torque at spindle: 1.220 Nm

Travel

- X-axis: +710/-710 mm
- Z-axis: 1000 mm
- C-axis: 360°

Feeds and rapid travels

- Travel in X- and Z-axis stepless: 0,1 – 3.000 mm/min.
- Rapid travel in X- und Z-axis: 15 m/min.
- Travel C-axis: 0,01 – 7 rpm
- Rapid travel C-axis: 7 rpm

Machine can be inspected under power!
