ENGEL - VICTORY 650-120 Tech - 2008 - Injection moulding machine

Current bid
Status

Total bid amount

See total breakdown

Max bid amount

See total breakdown
Lot specifications
Quantity
1
Margin
No
Brand
ENGEL
Type
VICTORY 650-120 Tech
Year of build
2008
Screw diameter
45mm
Injection volume
318cm³
Injection pressure
1525bar
Closing force
1200kN
Hours on display
59934
Machine weight
7600kg
Total dimension L
4860mm
Total dimension W
1500mm
Total dimension Height
2100mm
Terms of delivery
Free on truck
Description

Technical data closing page

Clamping force: 1200 kN
Panel size h x v: 740 x 680 mm
Min. installation height: 300 mm
Plate spacing max.: 800 mm
Opening travel: 507 mm
Ejector stroke: 130 mm
Ejector force: 40 kN
Centering of movable plate D: 125 mm
Centering of fixed plate D: 125 mm
Tool weight: 825 kg

Technical Data Spray Side

Screw diameter: 45 mm
Displacement: 318 cc
Spray pressure: 1525 bar
Screw length: 20 l/d
Screw stroke: 200 mm
Screw speed: 290 min
Injection flow to the outside: 220 g/s hp
Number of heating zones: 5
Nozzle travel: 300 mm

Dimensions & Weight

Machine dimensions LxWxH: 4.86m x 1.5m x 2.1m
Total Weight: 7600KG

Equipment

Screen text German
CEE socket 16A
Core pull hydraulic 2x
Air valve 2x
Machine with water battery
Machine without material hopper
Levelling elements
Schuko socket 10A
Tool heater 8x
Remarks
Function-tested injection moulding machine!
A tour with a test run is possible!
Additional details
Loading conditions: free loading truck Pick-up days 10 to 13.03.2026 and 16 to 20.03.2026 09:00 to 16:00 by appointment. Exact pick-up information can be found on the last page of the invoice. Business buyers from the European Union (EU) and non-EU countries (third countries) are obliged to pay a deposit to Troostwijk Deutschland on their total purchase. This deposit is calculated on the basis of the VAT rate applicable in the Federal Republic of Germany. After confirmation that the purchased lot has left the EU, the deposit will be returned to the buyer: • EU buyers must complete a completed confirmation of success [download the template "Template_Intra-Community Supply (DE-EN)" attached here] to Troostwijk Germany and return the deposit to export.de@troostwijkauctions.com in order to receive a refund. • Non-EU buyers must return a copy of the electronic export declaration (EX-A with MRN - for verification only) or, if the value of the goods is lower, a completed export declaration with a stamp from the EU border customs office to export.de@troostwijkauctions.com in order to get the deposit refunded.
Video

See the details and take a closer look at the item in this video.

3240%2520Video%2520ENGEL%2520Victory%2520650-120%2520Tech.mp4
