GILDEMEISTER NEF 500 PLUS CNC Lathe
- Current bid
- Status
€
Total bid amount
See total breakdown
Total bid amount
See total breakdown
€
Max bid amount
See total breakdown
Max bid amount
See total breakdown
Lot specifications
- Quantity
- 1
- Margin
- No
- Brand
- GILDEMEISTER
- Type
- NEF 500 PLUS
- Machine weight
- 3200kg
- Dimension l
- 3000mm
- Dimension w
- 1800mm
- Dimension h
- 1800mm
- Terms of delivery
- Loaded on truck
Description
Description of the machine:
This machine is suitable for turning chuck and shaft workpieces. The
commercial steel grades, cast iron, copper, aluminum, brass, gunmetal and
cuttable plastic can be rotated on this machine.
--> Concept of the N.E.F. plus
The machine comes standard with the equipment described below
delivered
- Cycle control
- AC main drive
- Combination carriage with AC drive and control panel
- Tailstock movable with tailstock tensioner, manually clamped, with
downstream centering tip
- Coolant supply
- Chip protection hoods, manually operated
- Protective cover for chucks
- Quick-change tool holder Hahn & Kolb Multifix C
- Reducing ring for turning spindle
Accessories according to pictures:
- 2 pcs bezels
- Various clamping jaws
- Hahn & Kolb Multifix Type C
- Various turning steel holders
Technical data:
Working Range:
- Circumferential diameter over bed: 500 mm
- Circumferential diameter above the radial slide: 285 mm
- Chuck Ø 250 (315) mm
- Face slide: 260 mm
- Distance between tips: 1000/1500 mm
Turning spindle:
- Spindle head DIN 55027: size 8
- Spindle hole diameter: 70 mm
- Spindle nose hollow cone: 80 metric
- Spindle diameter in the front bearing
Remarks
Item condition: used and unchecked
