MITUTOYO - PJ300 - Optical Profile Projector

Brand: Mitutoyo

Model No.: PJ300

Equipment Type: Optical Profile Projector

Overview:

- Optical measuring instrument designed to project the enlarged silhouette of parts onto a screen.

- Allows dimensional inspections to be carried out without direct contact with the part.

- Ideal for measuring contours, radii, threads, bevels, gears, and complex shapes

Approximate technical characteristics:

- Circular projection screen with coordinate grid.

- Interchangeable magnification lenses (usually 10x, 20x, 50x).

- Top (reflected) and bottom (transmitted) lighting, with independent controls.

- Coordinate table with micrometric displacement in X and Y axes.

Common Applications:

- Quality control in production and metrology.

- Measurement of turned, milled or stamped parts.

- Verification of molds, punches and serrated shapes.

remarks:

- It does not require contact with the part, which prevents deformations.

- High precision instrument widely used in precision workshops and mold and die industries.

Untested functionality
