TRUMPF SISMA - MYSINT 100 - Synthesizer - 2015
- Current bid
- Status
Total bid amount
See total breakdown
Total bid amount
See total breakdown
Max bid amount
See total breakdown
Max bid amount
See total breakdown
Lot specifications
- Quantity
- 1
- Margin
- No
- Brand
- TRUMPF SISMA
- Type
- MYSINT 100
- Year of build
- 2015
Description
Main
technical data Manufacturer: SISMA S.p.A. / TRUMPF SISMA
Model: MYSINT 100
Type: Machine for Laser Metal Fusion / Selective Laser Melting of Metal Powders
Working process: selective laser melting of overlapping
metal powder layers Powder layer thickness: 10 - 30 μm
Machinable materials: metal powders authorized by the manufacturer
Laser System Class: Class 1 in Standard
Mode Maximum laser power: 150 W CW, shown in the technical
data table Laser wavelength: 1064 nm
Machine dimensions: 1390 x 760 x 1574 mm
Working chamber: Ø 100 x 160 mm
Machine weight: 650 kg
Power supply: 220-240 V single phase
Frequency: 50/60 Hz
Maximum power consumption: 1 kVA
Maximum current consumption: 7 A
Network connection: Ethernet 1 Gb/s, RJ45
socket Technical gas: nitrogen or argon
Inert gas supply pressure: 2 - 5 bar
Inert gas working pressure: 1.8 bar
Gas consumption: < 0.3 l/min
Working ambient temperature: +15 °C / +30 °C
Recommended relative humidity: < 75%, non-condensing
Noise level: < 70 dB
technical data Manufacturer: SISMA S.p.A. / TRUMPF SISMA
Model: MYSINT 100
Type: Machine for Laser Metal Fusion / Selective Laser Melting of Metal Powders
Working process: selective laser melting of overlapping
metal powder layers Powder layer thickness: 10 - 30 μm
Machinable materials: metal powders authorized by the manufacturer
Laser System Class: Class 1 in Standard
Mode Maximum laser power: 150 W CW, shown in the technical
data table Laser wavelength: 1064 nm
Machine dimensions: 1390 x 760 x 1574 mm
Working chamber: Ø 100 x 160 mm
Machine weight: 650 kg
Power supply: 220-240 V single phase
Frequency: 50/60 Hz
Maximum power consumption: 1 kVA
Maximum current consumption: 7 A
Network connection: Ethernet 1 Gb/s, RJ45
socket Technical gas: nitrogen or argon
Inert gas supply pressure: 2 - 5 bar
Inert gas working pressure: 1.8 bar
Gas consumption: < 0.3 l/min
Working ambient temperature: +15 °C / +30 °C
Recommended relative humidity: < 75%, non-condensing
Noise level: < 70 dB
